Band Saw

500*700 MM High speed heavy duty metal cutting band saw machine

Max cutting size: 500*700mm
Motor power 7.5kw
Inverter speed
chip conveyor
hydraulic blade tension
Hydraulic table feeding material
Everising type band saw machine

Benefits at a glance

Automatic band saw machine Features :

Sawing speed increased by 50%

saw blade life increased by 50%

machining accuracy increased by 50%

equipment service life increased by 50%

Model No.	H-70/50P
Technical Data	Cutting capacity(mm)	500mm 500HX700W
	Blade speed(m/min)	15-80 m/Min
	Blade size(mm)	1.3×41*5450
	Main Motor(kw)	7.5
	Hydraulic Motor(kw)	1.5
	Work piece Clamping	Hydraulic Vise
	Blade Tension	Hydraulic
	Chip clean	Chip conveyor
	Main Drive	Worm wheel drive
	Material feed	Hydraulic Plate table
	Feeding table length	7001200mm (widthlength)
	Machine size	2950×2700×2200
	Machine weight	3000kg
Standard Equipment	Blade Cleaning brush	Power blade cleaning brush
	Working light	YES
	One piece of bi-metal saw blade	YES
	One set of tools with tool box	YES
	Operation manual	YES


500*700 MM High speed heavy duty metal cutting band saw machine

More,Stronger, Faster,Stable ,Efficiency,Short Tailing
